Packinox
A Packinox heat exchanger is ideal for demanding heat recovery duties in processes with high pressures and temperatures. Its outstanding thermal performance, superior hydraulic efficiency and low CAPEX allow you to optimize energy efficiency, increase profitability and improve sustainability. A Packinox enables higher yield and recovers more heat than a shell-and-tube solution, resulting in better ROI and a lower environmental impact. Packinox is also available as plate-and-frame configuration.
Reliable efficiency
- Lower OPEX – The high heat recovery leads to substantial energy savings. Maintenance costs are also low thanks to minimal fouling.
- Lower CAPEX – A single Packinox can replace several large shell-and-tubes and makes it possible to operate processes with smaller furnaces and cooling
- Higher process yield thanks to a low pressure drop, optimal liquid/gas mixing, high operating flexibility and a fully customized design.
- Reliable, proven technology – More than 350 units in operation worldwide.
- Real-time monitoring and continuous optimization by Alfa Laval experts.
Packinox+
Thanks to our new FlexFlow technology, a Packinox+ heat exchanger can be optimized for highly asymmetric flows and offers a range of flow configurations, including multi-stream arrangements, making it highly suitable for a broad spectrum of demanding process duties.
Solusi berkelanjutan
Bayangkan dunia yang lebih berkelanjutan. Dunia yang hemat energi untuk menghasilkan lebih banyak lagi. Dunia yang secara efisien memenuhi permintaan energi yang terus meningkat dan secara bersamaan mengurangi emisi CO2. Bayangkan dunia tempat kita dapat memanfaatkan kekayaan sumber daya alam, sekaligus melestarikannya. Di Alfa Laval, kami tidak hanya membayangkannya saja. Kami sedang mewujudkannya – bersama dengan pelanggan dan mitra kami.
Packinox plate-and-frame heat exchanger
The plate-and-frame version of Alfa Laval Packinox has no pressure shell and no Spray Bar system. It is suitable for applications where the extra pressure and temperature resistance provided by the shell is not required, and where no separate liquid feed injection/flash evaporation takes place inside the heat exchanger. Applications include carbon capture and storage, energy storage, oil refining, petrochemicals and many more.
Sempurnakan kilang Anda
Setelah bermitra dengan Alfa Laval, Anda mendapatkan akses ke berbagai layanan pengoptimalan proses. Layanan ini mencakup semua tahapan proyek Anda mulai dari pembuatan ide awal, proses studi desain dasar dan kelayakan, hingga instalasi dan uji kelaikan peralatan kami. Bekerja sama dengan pemberi lisensi, perusahaan teknik, dan pengguna akhir, tim kilang Alfa Laval menghadirkan keahlian terkemuka di dunia dalam optimalisasi proses semua jenis proyek kilang, memaksimalkan kemungkinan keberhasilan proyek dan ROI.
Unique HyperCut plate design improves thermal efficiency
Alfa Laval’s unique HyperCut heat transfer plates have many benefits:
- 50% lower pressure drop over the distribution areas compared to the previous design. This makes it possible to either increase heat recovery, reduce the size of the heat exchanger or to lower the overall pressure in the process.
- 30% higher mechanical strength and higher resistance to thermo-mechanical stress.
- Improved flow and pressure distribution, which improves operability.
How it works
The recycle gas enters the heat exchanger at the bottom and passes the Spray Bars on its way into the plate pack. The liquid feed enters from the side and is sprayed into the gas by the Spray Bars. This ensures a perfect mix of liquid feed and recycle gas, which facilitates lifting and makes it possible to operate the unit on a high liquid-to-gas ratio for maximum yield.
The feed/gas mixture moves up through the plate pack while the reactor effluent travels in the opposite direction. The highly turbulent, counter-current flow ensures that most of the heat from the reactor effluent is recovered and heats the cold feed. The hot approach temperature can be as low as 25°C (45°F).
The outstanding heat recovery reduces the load on both the reactor heater and the cooling system compared to using other types of heat exchangers, thereby reducing both OPEX and CAPEX.
Customer stories
Learn how companies around the world, in various industries, have ensured maximum flexibility, reliability and yield with Alfa Laval Packinox heat exchangers.
Unique features
Explosion Forming
High-strength plates with long, reliable lifetime
HyperCut
Unique plate design that increases reliability and reduces pressure drop
Spray Bar
Effective mixing of the liquid feed and the recycle gas (applicable for the plate-and-shell model only)
ALOnline
Digital services for maximum uptime and performance
ALOnsite
Qualified support at your facility
Plate Wash
Monitors the pressure drop in the heat exchanger and allows operators to engage water cleaning whenever ammonium salt fouling begins to accumulate.
